linzmf

Linear z-shaped saturation membership function

Since R2022a

collapse all in page

Syntax

y = linzmf(x,params)

Description

This function computes fuzzy membership values using a linear z-shaped membership function. You can also compute this membership function using a fismf object. For more information, see fismf Object.

This membership function is related to the trimf, trapmf, and linsmf membership functions.

y = linzmf(x,params) returns fuzzy membership values computed using a linear z-shaped saturation membership function.

  • When a < b:

    f(x;a,b)={1,x<ab−xb−a,a≤x≤b0,x>b}

  • When a = b:

    f(x;a,b)={1,x<a0,x≥a}

To define the membership function parameters, specify params as the vector [a b].

Membership values are computed for each input value in x.

example

Examples

collapse all

Open Live Script

Specify input values across the universe of discourse.

x = 0:0.1:10;

Evaluate a linear z-shaped membership function for the input values.

y = linzmf(x,[4 6]);

Plot the membership function.

plot(x,y)
xlabel('linzmf, P = [4 6]')
ylabel('Membership')
ylim([-0.05 1.05])

Figure contains an axes object. The axes object with xlabel linzmf, P = [4 6], ylabel Membership contains an object of type line.

Input Arguments

collapse all

Input values for which to compute membership values, specified as a scalar or vector.

Membership function parameters, specified as the vector [a b]. Parameter a defines the shoulder of the membership function, and b defines its foot. Setting a equal to b produces a crisp membership function.

Output Arguments

collapse all

Membership value, returned as a scalar or a vector. The dimensions of y match the dimensions of x. Each element of y is the membership value computed for the corresponding element of x.

Alternative Functionality

fismf Object

You can create and evaluate a fismf object that implements the linsmf membership function.

mf = fismf("linzmf",P);
Y = evalmf(mf,X);

Here, X, P, and Y correspond to the x, params, and y arguments of linzmf, respectively.

Extended Capabilities

C/C++ Code Generation
Generate C and C++ code using MATLAB® Coder™.

Version History

Introduced in R2022a
