Output total execution time in Run in Kernel mode
Simulink Desktop Real-Time / Target Profiling
In Run in Kernel mode, this block outputs the execution time.
In Connected IO mode, this block does not perform any action. It outputs zeros.
Total Exec Time — Total execution time for the previous base rate tick
Presents the total execution time as of the previous sample time.
Task Exec Time — Task execution times for individual sample rates (optional)
vector of double
Presents the task execution times for individual sample rates in a multitasking model as of the previous sample time.
When you select Measure task execution times, this port is visible.
Measure task execution times — Show task execution times for individual tasks
‘off’ (default) |
Makes visible the port
Task Exec Time, which
presents the task execution times for individual sample rates in a
multitasking model as of the previous sample time.
Introduced in R2017a
