Gypaets/trigradient​2

版本 1.1.0.0 (3.7 KB) 作者: Gypaets
First and second order derivative calculation for scattered data. Fast and accurate method.
425.0 次下载
更新时间 2017/6/29

[ZX, ZY, ZXX, ZYY, ZXY] = trigradient2(X, Y, Z, T, M)
The derivatives of the function Z(X,Y) are calculated with a least squares linear regression. The system of equations is set up with Taylor series from each point to the adjacent vertices. If a vertex is connected to less than five vertices then vertices in two-edge distance are used too.
This derivation method provides much better results than first order approaches. Specially the error of the calculated second order field derivatives is significantly smaller than deriving two times the field with a first order function.
Input:
X= Vector with x-coordinates.
Y= Vector with y-coordinates.
Z= Matrix with function values on each point. If Z has multiple
columns the derivatives for each column are calculated.
Optional argument:
T= Triangulation (Nx3 matrix with polygon vertices). If not given the delaunay triangulation of X,Y is used.
M= Method used for calculation. Default value is 0.
0: One large equation system. Fast.
1: Multiple small equations systems. Slower but depending on the input values more accurate.

Output:
ZX=dz/dx
ZY=dz/dy
ZXX=d^2z/dx^2
ZYY=d^2z/dy^2
ZXY=d^2z/(dx dy)

引用格式

Gypaets (2024). Gypaets/trigradient2 (https://github.com/Gypaets/trigradient2), GitHub. 检索时间: .

MATLAB 版本兼容性
创建方式 R2015b
兼容任何版本
平台兼容性
Windows macOS Linux
类别
Help CenterMATLAB Answers 中查找有关 Delaunay Triangulation 的更多信息
致谢

参考作品: TRIGRADIENT.M

Community Treasure Hunt

Find the treasures in MATLAB Central and discover how the community can help you!

Start Hunting!

无法下载基于 GitHub 默认分支的版本

版本 已发布 发行说明
1.1.0.0

Repo update.
Linked to github repository.
Corrected a typo.
Provided alternative 'repelem' to make trigradient2.m compatible with Matlab versions older than 2015.
Added alternative calculation method with many small systems instead of only a large one.
Updated description.
File description update

1.0.0.0

File description update
