5G NR RF 系统仿真

利用 5G Toolbox™，您能够对 NR 发射机和接收机中射频 (RF) 损伤的影响进行表征。

App

5G 波形发生器创建、减损、可视化和导出 5G NR 波形

函数

nrPhaseNoiseAdd NR phase noise to signal (自 R2026a 起)

模块

Waveform From Wireless Waveform Generator App blockWaveform From Wireless Waveform Generator App导出到 Simulink 的无线波形源

精选示例

Modeling and Testing an NR RF Transmitter

Modeling and Testing an NR RF Transmitter

Characterize the impact of RF impairments, such as IQ imbalance, phase noise, and PA nonlinearities in an NR RF transmitter.

Modeling and Testing an NR RF Receiver with LTE Interference

Modeling and Testing an NR RF Receiver with LTE Interference

Characterize the impact of RF impairments of NR-TM waveforms when coexisting with LTE waveforms.

EVM Measurement of 5G NR Downlink Waveforms with RF Impairments

EVM Measurement of 5G NR Downlink Waveforms with RF Impairments

Measure EVM of NR-TM or NR-FRC waveforms with phase noise and memoryless nonlinearity impairments.

5G NR Downlink Carrier Aggregation, Demodulation, and Analysis

5G NR Downlink Carrier Aggregation, Demodulation, and Analysis

Generate, aggregate, and demodulate multiple 5G NR downlink carriers.

NR Phase Noise Modeling and Compensation

NR Phase Noise Modeling and Compensation

Analyze the impact of phase noise in a 5G OFDM system and use PT-RS in compensating the CPE.

使用 App 生成的模块在 Simulink 中生成无线波形

使用 App 生成的模块在 Simulink 中生成无线波形

使用无线波形发生器的导出到 Simulink 功能在 Simulink 中生成波形。
