验证

证明 MATLAB^® 代码与生成的代码之间的数值等效性

通过执行软件在环 (SIL) 和处理器在环 (PIL) 仿真，检查从 MATLAB 函数中生成的代码的数值行为。软件在环 (SIL) 仿真在开发计算机上编译生成的源代码并将其作为单独的进程执行。PIL 仿真（需要目标连接配置）交叉编译生成的源代码，然后在目标硬件上下载并运行目标代码。通过将 SIL 或 PIL 仿真的结果与原始 MATLAB 函数的结果进行比较，可以验证代码的数值行为。

您可以生成可追溯的代码，帮助您检查是否存在不需要的功能、了解生成的代码如何实现您的算法，并评估生成的代码质量。

对象

全部展开

目标连接

`rtw.connectivity.ComponentArgs`	Provide parameters for each target connectivity component
`rtw.connectivity.Config`	Define connectivity implementation that comprises builder, launcher, and communicator components
`rtw.connectivity.ConfigRegistry`	Register connectivity configuration
`rtw.connectivity.Launcher`	Control downloading, starting, and resetting of a target application
`rtw.connectivity.MakefileBuilder`	Configure toolchain-based build process
`rtw.connectivity.RtIOStreamHostCommunicator`	Configure development computer communications with target processor
`rtw.pil.RtIOStreamApplicationFramework`	Configure target-side communications

代码生成参数

coder.EmbeddedCodeConfig Configuration parameters for C/C++ code generation from MATLAB code with Embedded Coder

函数

全部展开

添加代码插桩

instrumentCode Add instrumentation to generated code to perform execution time / memory usage profiling and analyze code coverage (自 R2023a 起)

代码覆盖率分析

getCodeCoverageData Extract coverage data for generated C/C++ code and custom C/C++ code (MATLAB code generation) (自 R2023a 起)

硬件配置

coder.hardware Create hardware board configuration object for C/C++ code generation from MATLAB code

rtIOStream API

`rtIOStreamClose`	Shut down communications channel
`rtIOStreamOpen`	Initialize communications channel
`rtIOStreamRecv`	Receive data through communication channel
`rtIOStreamSend`	Send data through communication channel

连接测试

`rtiostreamtest`	Test custom `rtiostream` interface implementation
`rtiostream_wrapper`	Test `rtiostream` shared library functions in MATLAB
`piltest`	Verify custom target connectivity configuration for MATLAB PIL execution

主题

SIL 和 PIL 测试

Code Verification Through Software-in-the-Loop and Processor-in-the-Loop Execution
A workflow that uses SIL and PIL execution to verify the numerical behavior of generated MATLAB code.
使用 MATLAB Coder 的软件在环执行
使用 MATLAB Coder 验证生成的 C/C++ 代码的数值行为。
Software-in-the-Loop Execution from Command Line
Use MATLAB commands to verify the numerical behavior of generated C/C++ code.
Software-in-the-Loop Execution for MATLAB Function with Multiple Signatures
Generate a SIL MEX file for multiple signatures.
Debug Generated Code During SIL or PIL Execution
Use a debugger to understand the behavior of generated code.
Create PIL Target Connectivity Configuration for MATLAB
Customize PIL execution for your target environment.
Host-Target Communication for MATLAB PIL Execution
Use the rtiostream API for communication between your development computer and target during PIL execution.
Specify Hardware Timer for MATLAB
Specify a hardware timer using the Code Replacement Tool.
Custom Toolchain Directives Required for Code Execution Profiling
Specify compiler directives for building PIL application that supports code execution profiling.
Processor-in-the-Loop Execution with the MATLAB Coder App
Use the MATLAB Coder app to verify the numerical behavior of cross-compiled object code.
Processor-in-the-Loop Execution from Command Line
Use MATLAB commands to verify the numerical behavior of cross-compiled object code.
PIL Execution with ARM Cortex-A at the Command Line
This example shows how to set up a PIL execution to verify generated code at the command line.
PIL Execution with ARM Cortex-A by Using the MATLAB Coder App
PIL Execution with App.
Verification of Code Generation Assumptions
PIL execution checks Hardware tab settings.
Speed Up SIL/PIL Execution by Disabling Constant Input Checking and Global Data Synchronization
Configure code generation parameters to turn off constant input checking or global data synchronization for SIL or PIL executions.
SIL/PIL Execution Support and Limitations
SIL and PIL execution support for code generation features.

代码追溯

Interactively Trace Between MATLAB Code and Generated C/C++ Code
Visualize the mapping between the MATLAB code and the generated C/C++ code.
在生成的 C/C++ 代码中包含注释
在生成的代码中包含 MATLAB 源代码作为注释。在函数前注中包含函数帮助文本和函数签名。

Polyspace 验证

由 MATLAB Coder 生成的 C/C++ 代码的 Polyspace 验证
检查生成的 C/C++ 代码中的运行时错误或缺陷。

生成报告

Highlight Potential Data Type Issues in a Report
Highlight MATLAB code that results in double-precision, single-precision, or expensive fixed-point operations.
Find Potential Data Type Issues in Generated Code
Highlight potential data type issues in report.
