图像处理和计算机视觉
R2026b使用 Vision HDL Toolbox™ 模块创建并运行 HDL 应用程序
使用 MATLAB® 函数或 Simulink® 模块开发图像处理算法。您可以使用 Vision HDL Toolbox 中支持 HDL 代码生成的模块。Vision HDL Toolbox 提供了用于 FPGA 和 ASIC 的视觉系统设计和实现的像素流算法。
有关过滤后的支持 HDL 代码生成的 Vision HDL Toolbox 模块列表，请参阅 Vision HDL Toolbox 模块列表（HDL 代码生成） (Vision HDL Toolbox)。
主题
MATLAB 算法
- Generate HDL and HLS Code from a High Dynamic Range Imaging Algorithm
This example shows how to generate HDL and HLS code from a MATLAB design that implements a high dynamic range imaging algorithm. - 通过直方图均衡化进行图像增强
此示例说明如何从使用直方图均衡化进行图像增强的 MATLAB® 设计生成 HDL 代码。 - Generate HDL and HLS Code from an Adaptive Median Filter Algorithm
This example shows how to generate HDL and HLS code from a MATLAB design that implements an adaptive median filter for image noise removal. - Generate HDL and HLS Code from a Contrast Adjustment Algorithm
This example shows how to generate HDL and HLS code from a MATLAB design that adjusts image contrast by linearly scaling pixel values. - 从 RGB 到 YUV 的图像格式转换的 HDL 代码生成
此示例说明如何从将图像格式从 RGB 转换为 YUV 的 MATLAB® 设计生成 HDL 代码。
Simulink 算法
- Design Video Processing Algorithms for HDL in Simulink
This example shows how to design a hardware-targeted image filter using Vision HDL Toolbox™ blocks.
精选示例
Lane Detection
Implement a lane-marking detection algorithm for FPGAs.
Edge Detection and Image Overlay
Detect and highlight object edges in a video stream.
Accelerate Pixel-Streaming Designs Using MATLAB Coder
Accelerate a pixel-stream video processing algorithm in MATLAB® by using MATLAB Coder™.
Enhanced Edge Detection from Noisy Color Video
Develop a complex pixel-stream video processing algorithm, accelerate its simulation using MATLAB® Coder™, and generate HDL code from the design. The algorithm enhances the edge detection from noisy color video.
