An RF or microwave system contains several basic components such as transmission lines, couplers, power dividers, and combiners. Using the objects and functions in this category you can create, visualize, and analyze the characteristics of the components used on a printed circuit board (PCB).
You can also use the
design function to create and analyze
these PCB components to specific frequencies, impedances, and lengths. You can also any
PCB component into an RF Toolbox™ circuit object by using
