slreportgen.finder.DataDictionaryResult Class

Use the getReporter method of an slreportgen.finder.DataDictionaryResult object to access the data dictionary reporter for the result. Then, customize the reporter by setting its properties.

Import the MATLAB and Simulink Report API packages so that you do not have to use long, fully qualified class names.

import mlreportgen.report.*
import slreportgen.report.*

Create a Simulink report and add a table of contents.

rpt = slreportgen.report.Report("MyReport","html-file");
append(rpt,TableOfContents);

Create a dictionary finder that searches the entire MATLAB path. Find only data dictionaries with names that begin with slrgex__fuelsys.

f = slreportgen.finder.DataDictionaryFinder();
f.Name = "slrgex_fuelsys*";

Create a chapter with a section for each data dictionary result. For each result, customize the reporter to include only the Name, Value, and Class properties in the Design Data summary table.

ch = Chapter("Data Dictionaries");
while hasNext(f)
    result = next(f);
    s = Section(result.Name);
    rptr = getReporter(result);
    rptr.SummaryProperties = ["Name" "Value" "Class"];
    append(s,rptr);
    append(ch,s);
end

Add the chapter to the report. Close and view the report.

append(rpt,ch);
close(rpt);
rptview(rpt);

The report has a section for each of the found dictionaries, slrgex_fuelsys.sldd and slrgex_fuelsys_fuel_rate_control.sldd. The summary table for each dictionary includes only the Name, Value, and Class properties.
