Link-level block error rate simulation with 5G NR clustered delay line (CDL) and tapped delay line (TDL) channel models

Use 5G Toolbox™ System objects to model multi-input multi-output (MIMO) fading channels with different delay profiles. The examples on this page show various link-level block error rate (BLER) simulations with TDL and CDL channel models.

System Objects

nrCDLChannelSend signal through CDL channel model
nrTDLChannelSend signal through TDL channel model

Topics

Transmission over MIMO Channel Model with Delay Profile TDL

This examples displays the waveform spectrum received through a TDL MIMO channel.

Plot Path Gains for TDL-E Delay Profile with SISO

This examples plots the path gains of a TDL single-input single-output (SISO) channel.

Reconstruct Channel Impulse Response Using CDL Channel Path Filters

This examples reconstructs the channel impulse response and estimates timing offset using path filters of a CDL channel model.
