应用示例
浏览说明 Infineon® AURIX™ TC4x 硬件的电源转换和电机控制应用的建模、控制和仿真示例。
精选示例
使用 Infineon AURIX 微控制器与编码器对 BLDC 进行磁场定向控制
此示例说明如何实现磁场定向控制 (FOC) 方法来控制三相无刷直流 (BLDC) 电机的转速。FOC 算法需要转子位置反馈，这是通过使用编码器获得的。有关 FOC 的更多详细信息，请参阅磁场定向控制 (FOC) (Motor Control Blockset)。
Model DC-DC Buck Converter Using Infineon AURIX
Model a DC-DC buck converter application that converts the voltage from 48 V to 12 V using the Infineon® AURIX™ TC4x microcontroller.
Analyze Sensorless Observers for Field-Oriented Control Using Multiple Cores of Infineon AURIX
Use Embedded Coder® Support Package for Infineon® AURIX™ Microcontrollers for sensorless field-oriented control using multiple cores of an Infineon AURIX microcontroller board. This example uses a top-level model and two referenced models. You use the TriCore0 referenced model to implement a sensor-based field-oriented control (FOC) technique to control the speed of a three-phase brushless DC (BLDC) motor. You use the TriCore1 referenced model to implement and analyze different sensorless algorithms, such as the algorithms implemented in the Flux Observer (Motor Control Blockset), 滑动模式观测器 (Motor Control Blockset), and Extended EMF Observer (Motor Control Blockset) blocks.
Accelerate AI Based Software Development on Infineon AURIX TC4x Microcontroller
Implement AI based motor control functions using the Model-Based Design approach by deploying a multi-layer perceptron (MLP) neural network on the Infineon® AURIX™ TC4x microcontroller.
Generate and Deploy Optimized Code for Digit Classification Deep Learning Network on Infineon PPU Target
Generate and deploy optimized code for a digit classification deep learning network to run on an Infineon® AURIX™ TC4x PPU.
