visualizePhaseNoise

Plot phase noise characteristics of idealized mixer

Since R2024b

collapse all in page

Syntax

visualizePhaseNoise(idbbobj)

visualizePhaseNoise(idbbobj,hfig)

Description

visualizePhaseNoise(idbbobj) plots the phase noise characteristics of an idealized mixer idbbobj.

example

visualizePhaseNoise(idbbobj,hfig) plots the phase noise characteristics of an idealized mixer in the figure specified in hfig.

Examples

collapse all

Visualize Phase Noise Characteristics of RF mixer

Open Live Script

Create an RF mixer with phase noise.

rfmix = rf.Mixer(IncludePhaseNoise=1,PhaseNoiseLevel=[-145, -150],...
    PhaseNoiseAutoResolution=0,PhaseNoiseFrequencyOffset=[1000 5000], PhaseNoiseNumSamples=8);

Visualize the phase noise characteristics of the RF mixer.

visualizePhaseNoise(rfmix)

Figure rfmix contains an axes object. The axes object with title Phase Noise Magnitude Response, xlabel Frequency (Estimated Sample Rate=12500 Hz with Resolution=781.25 Hz), ylabel dBc/Hz contains 3 objects of type line. One or more of the lines displays its values using only markers These objects represent Filter Response, Design Specification, Phase Noise Specification.
