Euro NCAP Test Suite

Generate test specifications, seed scenarios, and scenario variants for automated driving standards like Euro NCAP and evaluate test metrics

The Automated Driving Toolbox™ Test Suite for Euro NCAP^® Protocols support package enables you to automatically generate specifications for various Euro NCAP^® tests, which include safety assessments of automated driving applications such as Safety Assist Tests and Vulnerable Road User (VRU) Protection Tests. You can create a seed scenario for a Euro NCAP test, and vary parameters such as, scene parameters, actor parameters, and simulator parameters to generate variants of it. Use these scenario variations for safety assessment of different automated driving applications, such as autonomous emergency braking (AEB) car-to-car and AEB car-to-pedestrian scenarios. For more information, see Get Started with Euro NCAP Test Suite.

To automatically generate seed scenarios for the Euro NCAP test protocols, and to generate their scenario variants, download and install the Automated Driving Toolbox Test Suite for Euro NCAP Protocols support package from the Automated Driving Toolbox Test Suite for Euro NCAP Protocols Add-On. For more information on downloading add-ons, see Get and Manage Add-Ons.

Functions

expand all

Euro NCAP Test Specification

`ncapSpec`	Obtain Euro NCAP test specifications (Since R2024a)
`ncapScenario`	Generate scenario descriptors for Euro NCAP test (Since R2024a)
`table2scenario`	Generate scene and scenario from tabular data (Since R2024a)
`identifyActorOfInterest`	Identify ego and target actors in seed scenario descriptor (Since R2023b)
`generateWaypoints`	Generate waypoints to perform lane change and lane drift (Since R2024a)

Scenario Variant Generation

`getScenarioDescriptor`	Extract properties from input scenario to generate scenario variants (Since R2022b)
`getCollisionData`	Get collision information of colliding actors (Since R2023a)
`plot`	Plot scenario descriptor (Since R2026a)
`seek`	Seek and plot scenario frame in scenario descriptor (Since R2026a)
`play`	Play scenario simulation from scenario descriptor (Since R2026a)
`variationProperties`	Store scenario property variations (Since R2023a)
`varyActorProperties`	Add variations to actor properties (Since R2023a)
`varyCollisionProperties`	Add variations to collision properties (Since R2023a)
`varySceneProperties`	Add variations to scene properties (Since R2024b)
`varyTestProperties`	Add variations to Euro NCAP test bench properties (Since R2024b)
`generateVariants`	Generate variant scenario descriptors from seed scenario descriptor using specified variations (Since R2023a)
`getScenario`	Get scenario object from scenario descriptor object (Since R2022b)

Euro NCAP Test Report Generation

`euroAssessment`	Store Euro NCAP assessment protocol specifications (Since R2025a)
`assessmentTable`	Create empty assessment table for Euro NCAP test scenario (Since R2025a)
`ncapScore`	Obtain score for Euro NCAP test (Since R2025a)
`ncapReport`	Generate report from Euro NCAP test scenario assessment results (Since R2026a)
`exportReport`	Export report of Euro NCAP test scenario assessment results (Since R2026a)

Topics

Getting Started

Get Started with Euro NCAP Test Suite

Learn the basics of generating a seed scenario descriptor for Euro NCAP tests, generating scenario variants, simulating a driving test bench, and generating a test report.
- STEP 1: Generate Custom Seed Scenario Descriptor or Seed Scenario Descriptor for Euro NCAP Test
- STEP 2: Vary Seed Scenario Parameters and Generate Scenario Variants
- STEP 3: Set Up and Configure Driving Test Bench to Simulate Scenario Variants
- STEP 4: Generate Test Report
Translate Scenario Between Driving Scenario and RoadRunner Scenario
Learn the process of translating scenarios between driving scenario and RoadRunner Scenario
Create Routes Similar to Seed Actor Trajectory in Scenes
Create routes similar to seed actor trajectory in scenes.
Translocate Collision from Seed Scenario to Target Scene
Translocate collision from RoadRunner seed scenario to target scene.

Seed and Variant Scenario Generation

Generate RoadRunner Scenario Using Tabular Data for AEB Car-to-Car Testing
Generate RoadRunner scenario using tabular data for AEB car-to-car testing. (Since R2024a)
Generate Variants for Testing AEB Car-to-Car Scenarios
Generate variants for testing AEB car-to-car scenarios. (Since R2024a)
Generate Variants of ACC Target Cut-In Scenario
Generate scenario variants to test adaptive cruise control (ACC) application using European New Car Assessment Programme (Euro NCAP) test scenario in which the target vehicle cuts in front of the ego vehicle.
Generate Scenario Variants Using Excel Spreadsheets
Generate scenario variants using Excel spreadsheets.

Driving Simulation Test Bench

Overview of Driving Simulation Test Bench
Learn the basics of simulating a driving test bench.
AEB Test Bench for Euro NCAP Scenarios
Configure AEB test bench designed in Simulink^® and simulate a scenario in RoadRunner Scenario per Euro NCAP testing protocols. (Since R2024a)

Featured Examples

Generate Scenario Variants for Testing AEB Pedestrian Systems

Generate scenario variants to test automated emergency braking (AEB) system using car-to-pedestrian European New Car Assessment Programme (Euro NCAP) test scenario.

Open Live Script

Generate Scenario Variants for Testing ACC Systems

Modify speeds of the ego and target vehicles to generate scenario variants for testing adaptive cruise control (ACC) application using European New Car Assessment Programme (Euro NCAP) test scenario.
