Suspension

Independent and solid axle suspensions

The independent and solid axle suspension blocks model the suspension compliance, damping, and geometric effects as functions of the relative positions and velocities of the vehicle and wheel carrier. Using the suspension compliance and damping, the blocks calculate suspension forces on the vehicle and wheels. You can specify:

Multiple axles per vehicle.
Multiple wheels per axle.
Suspension parameters per axle.
An anti-sway bar for independent suspensions.

Blocks

Independent Suspension - Air Spring	Air spring independent suspension (Since R2023b)
Independent Suspension - Double Wishbone	Double wishbone independent suspension
Independent Suspension - K and C	Independent kinematics and compliance test suspension (Since R2022a)
Independent Suspension - MacPherson	MacPherson independent suspension
Independent Suspension - Mapped	Mapped independent suspension
Twist-Beam Suspension - K and C	Twist-beam kinematics and compliance test suspension (Since R2022b)
Solid Axle Suspension	Solid axle suspension for multiple axles
Solid Axle Suspension - Air Spring	Air spring solid axle suspension (Since R2023b)
Solid Axle Suspension - Coil Spring	Solid axle suspension with coil spring
Solid Axle Suspension - Leaf Spring	Solid axle suspension with leaf spring
Solid Axle Suspension - Mapped	Mapped solid axle suspension

Topics

Coordinate Systems in Vehicle Dynamics Blockset
Understand coordinate systems for representing vehicle dynamics.
Kinematics and Compliance Virtual Test Laboratory
Virtually calibrate suspension blocks using this reference application.

Featured Examples

Kinematics and Compliance Virtual Test Laboratory Reference Application

Generate optimized suspension parameters for the vehicle dynamics mapped suspension blocks.

Open Script
