Signal and Data Processing

Create waveform libraries, estimate detection ranges, angles, and Doppler, perform clustering and tracking of detections, perform search and track

Use the Radar Toolbox to perform signal processing operations on recorded and simulated radar data. Typical operations include matched filtering and stretch-processing pulse compression, coherent and noncoherent pulse integration, and constant false alarm rate (CFAR) detection. You can estimate target range, direction of arrival, and speed. Extended objects produce clusters of detections that belong to the same object and can be associated into a single detection. The multi-object tracker associates detections and tracks. Simulate multifunction and cognitive radar as a closed loop, where radar parameters such as operating frequency, beam direction, and waveform selection change during the simulation.

Featured Examples

New

Cooperative Bistatic Radar I/Q Simulation and Processing

Simulate I/Q for a cooperative bistatic system and perform subsequent signal processing for a single bistatic transmitter and receiver pair.

Since R2024b
Open Live Script

Accelerating Radar Signal Processing Using GPU

Compare the performance of a conventional radar signal processing chain implemented in interpreted MATLAB and on a graphical processing unit (GPU).

Since R2024a
Open Live Script

Waveform Design and Signal Processing of Stepped Frequency Modulated Radar

Generate waveform level radar detections and range estimates for a stepped-frequency modulated waveform using a radarTransceiver in a radar scenario.

Since R2023a
Open Live Script

Waveform Parameter Extraction from Received Pulse

Simulate a scenario with a radar warning receiver (RWR) that detects radar emission and warns the pilot when the radar signal shines on the aircraft.

Since R2021b
Open Live Script

Search and Track Scheduling for Multifunction Phased Array Radar

Simulate a multifunction phased array radar system.

Since R2021a
Open Script

Automotive Adaptive Cruise Control Using FMCW and MFSK Technology

Model an automotive radar in Simulink^® that includes adaptive cruise control.

Since R2021a
Open Script

Doppler Estimation

A monostatic pulse radar detecting the radial velocity of moving targets at specific ranges.

Since R2021b
Open Live Script

Constant False Alarm Rate (CFAR) Detection

Introduces constant false alarm rate (CFAR) detection and shows how to use CFARDetector and CFARDetector2D to perform cell averaging CFAR detection.
