Patch Antennas

Miniaturize Rectangular Microstrip Patch Antenna Using Genetic Algorithm Optimization

Miniaturize rectangular microstrip patch antenna using Genetic Algorithm (GA) optimization.

Artificial Intelligence (AI) for Rapid Analysis and Design of Patch Antenna

Use artificial intelligence (AI) to rapidly analyze and design antennas from the Antenna Toolbox™ catalog.

Train Machine Learning Model for Analysis of Custom Antenna

Demonstrates how to apply machine learning to antenna analysis, and it illustrates a general recipe that you can use to train machine learning models to characterize antenna structures modeled and simulated in Antenna Toolbox™.

Sensitivity Analysis for Antenna Using Monte-Carlo Simulation

A workflow for the sensitivity analysis of microstrip patch antenna gain using the design space sampling. You explore the design of a microstrip patch antenna to study the sensitivity with respect to different design parameters of the antenna. The design includes uncertainty for the patch and ground plane width. You explore the rectangular microstrip patch antenna design by characterizing design parameters using probability distributions. Generate the values of the patch width and ground plane width from random samples of the distribution functions and perform Monte-Carlo simulation of the design at each of the sample data points. You then visualize the design space to select the best design. Using the sampled design space, you perform Monte-Carlo evaluation and use the result to analyze the influence of design parameters on the design.

Design and Simulate Monopulse Tracking System

Model and simulate a monopulse tracking system with a transmitter antenna, receiver antenna, and comparator.

(RF Blockset)

Analysis of Ultrawideband Trident Inset-Fed Monopole Antenna with Conical Ground

Analyze the performance of a U-shaped monopole antenna designed on a PCB and mounted on a conical ground. You achieve low-frequency matching by inserting a trident inset feed. The conical ground with an elliptical shape at the base of the radiator outperforms traditional UWB monopole designs in impedance-matching bandwidth and radiation pattern omnidirectivity [1].

Dual-Fed Square Microstrip Patch Antenna for BLE Applications

Design and analyze the dual-fed square microstrip patch antenna for Bluetooth Low Energy applications.

(RF PCB Toolbox)

Corporate Feed Divider Network for a Linear Patch Antenna array

Integrate a corporate power divider with a microstrip patch antenna array. The corporate power divider is available as a catalog element in RF PCB Toolbox. The patch antenna array is built using the patchMicrostripInsetfed catalog element and pcbStack from Antenna Toolbox.

(RF PCB Toolbox)

Design S-Band Monopulse Tracking Radar Antenna

Implement a monopulse operation by integrating a 2-by-4 microstrip patch array and a rat-race coupler.

ISM Band Patch Microstrip Antennas and Mutually Coupled Patches

Design and implement a rectangular, circular, triangular and elliptical patch microstrip antennas complying with the ISM (Industrial Scientific and Medical) band.

Patch Antenna with Dielectric Substrate

Calculates the performance of two linearly polarized patch antennas.

Design PIFA for WLAN Wi-Fi Applications

This example designs a PIFA for wireless applications.

Polarization Analysis of X-band Microstrip Patch Antenna

Perform polarization analysis on a microstrip patch antenna with the air substrate. The dimensions of this antenna are referenced from [1] for the center frequency of 10.35 GHz. In most basic form, a microstrip patch antenna consists of a radiating patch on one side of a dielectric substrate and a ground plane on the other side. Microstrip patch antennas radiate primarily as wide open-open half-wave microstrip resonators. The length L of the rectangular patch for the fundamental excitation mode is slightly less than λ/2. For a good antenna performance, a thick dielectric substrate having a low dielectric constant is usually desired since it provides a larger bandwidth and a well-defined beam. A rectangular microstrip patch antenna normally radiates a linearly polarized wave with about 6-7 dBi gain at broadside. Higher gains (up to 10 dBi) can be achieved by using different means including large patch heights and parasitic patches.

Analysis of Inset-Feed Patch Antenna on Dielectric Substrate

Showcases the analysis of an inset-feed patch antenna on a low-epsilon, low-loss, thin dielectric substrate. The results are compared with the reflection coefficient and surface currents around the 2.4 GHz, Wi-Fi band for a reference design [1]. The Antenna Toolbox™ library of antenna elements includes a patch antenna model that is driven with a coaxial probe. Another way to excite the patch is by using an inset-feed. The inset-feed is a simple way to excite the patch and allows for planar feeding techniques such as a microstrip line.

Design, Analyze, and Prototype 2-by-2 Patch Antenna Array

Create a 2-by-2 patch antenna array on an FR4 substrate, analyze the antenna, and generate PCB Gerber files for prototyping. The design operates at around 2.4 GHz.
