Extend Architectural Elements

System Composer™ provides built-in element types, including components, ports, connectors, interfaces, allocations, and functions. Functions are only available in software architectures. Create stereotypes to extend element types with metadata. Package related stereotypes into profiles for use with multiple models using the Profile Editor. Share profiles between models to ensure consistency within a project. Define stereotype hierarchies and change between these stereotypes dynamically in your model.

Stereotypes provide a template to define custom concepts and terminologies. Assign custom stereotypes to a model element to define its relation to the system. Properties defined within the stereotype applied to a model element can be used for early analyses, such as budget allocation, latency tradeoffs, and other parametric design concerns. You can add engineering units to property values to establish context.
